D013 dome Nut-sealed fiber optical splice closures are designed with a round or oval hat-shaped structure, and the closures can be opened without using specialized tool. The cover and bottom of the closures are sealed and fixed with the hoop locking, which is convenient for installation. this series of fiber optical splice closures are sealed by the nut compresses the elastomer and the seal ring automatically holds the cable. People can simply put the cable through the nut, the plastic washer (whose hole diameter substantially corresponds to that of the cable) and the taper elastomer seal ring, and then tighten the nut to keep the cable sealed. The fiber optical splice closures are suitable for the protection of various straight-through and branching connectors, and can be used for buried, manholes, pole mounting, wall and aerial installation.

Send Inquiry PDF Download
  • Description




Advanced internal structure design
Easy and fast to fix fiber cable
Fiber suffers no attenuation
The closure is spacious enough for winding and storing fibers
Fiber Optic Splice Trays(FOSTs) are design in SLIDE-IN-LOCK and its opening angle is about 90°
The curved diameter meets with international standard
Easy and fast to increase and reduce FOSTs
Innovative elastic intergrated seal fitting

Suitable for bunchy fibers
Underground, wall-mounting, hand hole-mounting, pole-mounting and duct-mounting
