OPTICAL DISTRIBUTION FRAME (Rack System)
EFON optical fiber distribution frame is made of top quality steel and deformed aluminum alloy and treated with galvanizing, oxidation and electrostatic plastic spraying, and it has the advantages of anti-corrosion, solid structure and pleasing appearance.
- Description
Description
Specifications
Packing
Features
There are 19” mounting rails in the middle of the frame for installing ODFs
Available color: white, black, grey or any other colors on request.
All the plastic elements in the frame are fire-resistant meets UL-94.
Reliable cable fixture cover and earth protection device/ grounding system provided.
A sticky label with the warning “Caution laser radiation” will be stuck to the frame.
Enough space for fiber distribution and storage space and very easy for installation and operation.
Fully front side operation, convenient for maintenances.
Minimum bend radius is controlled of 30mm.
Cable guides mounted on left and right side of canal are removable and relocatable to different positions within the same vertical line, to ensure a minimum bend radius of 30mm for the patch cords from any ODFs.
There are two lateral canals with separate doors (on left and right side of the frame) for distribution and management of fiber optical cables;
The side-hinged doors help to well protect the patch cords distribution area.
The optical cable inlet system is installed on the top or bottom of the frame which has excellent performances for fixing the incoming cables.
Cables can be entered to the frame either from top or the bottom of the frame subject to different requirements.
This Frame is suitable for both bundle (loose) cables and ribbon type cables.
